Perfect for applying cap designs and more.

Spur add-on sales and decorate the whole uniform with this easy-to-use cap heat press, designed to decorate caps of all sizes.

• The patented magnetic auto-open feature prevents over-application

• The hold-down device secures the cap and creates a smooth surface

• Decorate headwear of all shapes, styles, and sizes with available optional platens

• Easy-to-read digital time, temperature, and pressure display for consistent printing

• Locks down easily with a patented magnetic assist, causing less fatigue on wrists and shoulders

• Twin Timer™ allows users to pre-set individual time settings for two-step applications or for pre-heating and application

• Under-the-Center Pressure Adjustment ensures even, edge-to-edge heat and pressure

• Space-saving clam shell design
• Electrical Options:
  120 v; 4 amps; 500 w
  240 v; 2 amps; 500 w

• Must have a dedicated circuit breaker

• Proudly made in the USA



HOTRONIX® CAP AUTO PRESS SPECIFICATION



Universal Features

• Made in the USA
• Cast-in tubular heating
• Powder coated finish
• UL/ULC/CE



Details

• Size: 3.5″ x 6″
• Actual weight: 31 lbs.
• Ship weight: 41 lbs.
• Ship dim. 26” x 15” x 21”



Warranty

• Heating Element - Lifetime
• Framework - 5 years
• Circuit Board - 2 years
• Parts & Labor - 1 year

Optional Platens

• Choosing the right platen
• 2.75″ x 6.5″
• 3″ x 5.75″
• 4″ x 6.5″
• 4″ x 8″



PARTS LOCATION GUIDE





Download the Hotronix® Cap Heat Press Manual
