Delivers MAXXimum value for start-up businesses.

This affordable, easy-to-use heat press is perfect for start-ups or home-based businesses. It's also an excellent choice as a second heat press and portable for on-site heat printing.

• Three sizes available 16" x 20", 15" x 15", 11" x 15"

• Easy-to-read digital time and temperature display for consistent printing

• Wide opening for easy layout

• Space-saving clam shell design

• Patented Over-the-Center Pressure Adjustment for even, edge-to-edge heat and pressure regardless of substrate thickness

• Smooth-shock opening

• Coated non-stick heat platen

• Optional interchangeable lower platens are available

• 11 x 15 Electrical Options:
  120 v; 8.3 amps; 1000 w
  240 v; 4.5 amps; 1000 w

• 15 x 15, 16 x 20 Electrical Options:
  120 v; 15 amps; 1800 w
  240 v; 7.5 amps; 1800 w

• Must have dedicated circuit breaker

• Proudly made in the USA



SPECIFICATION

Universal Features

• Made in the USA
• Cast-in tubular heating
• Powder coated finish
• UL/ULC/CE



Details

• Actual weight: 62-94 lbs.
• Ship weight: 72-104 lbs.
• Ship dim. 36" x 25" x 21"



Warranty

• Heating Element - Lifetime
• Parts & Labor - 1 year



Optional Platens

• Choosing the right platen
• 7" round
• 6" x 10"
• 8" x 10"
• 11" x 15"



PART LOCATION GUIDE







Download  MAXX® Clam Heat Press Manual
